3. Getting to know the Booklet Maker
Take a few minutes to become familiar with the main components of the Booklet Maker.
3.1 Main components
Top cover
Upper pressure roller assembly (Only used for ON-line operation to Collator)
Press area, machine release (Press here and the Booklet Maker will be
released from the Collator and can be rolled
away)
Control panel
Fold stop assembly
Belt Stacker
(Optional accessory)
1.
2.
3.
4.
5.
6.
5
3
4
1 2
6
