Plockmatic BM 61 - Block Stapling - OFF-Line Option 1

T10165 OPERATOR MANUAL BM 61
19
4.1.5 Block stapling - OFF-line option 1
Lower the rear jogger by pressing the rear jogger unit forward (green marked).
Remove the upper pressure roller assembly.
Flip over the side jogger upper guides (both side joggers).
Open the top cover.
Set the side jogger to the correct paper size according to the scale.
Insert a set into the stapling area.
Move the rear side jogger up against the paper to verify that the side jogger aligns the
sheets.
NOTE: When checking the alignment, do not squeeze the release handle, only push
on top of the side jogger at the green label, to simulate the jogging action that the
BM 61 does during run.
T
urn the paper stop crank to position the set to the stapler.
Remove the set.
Position the stapler heads over the correct anvils.
Close the top cover.
Set the stapling switch to ON position.
Set the folding switch to OFF position.
Select manual or automatic start.
Flip down the fold stop to enable the sets to pass through the machine.
Set the power switch to ON position.
NOTE: By using the adapter (optional) either the Belt Stacker or the Delivery Tray can be
used for stacking of stapled sets.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
