Plum ecoMAX810P3-L TOUCH User Manual

24
11 Technical data
Voltage
230V~; 50Hz;
Current consumed by regulator
I = 0,04 A
3
Maximum rated current
6 (6) A
Regulator protection rating
IP20, IP00
4
Ambient temperature
0...50 C
Storage temperature
0...65 C
Relative humidity
5 - 85% without
vapour
condensation
Measuring range of temperature
sensors CT4
0...100 C
Measuring range of temperature
sensors CT4-P
-35...40 C
Accuracy of temperature
measurements with sensors CT4
and CT4-P
2 C
Temperature measure range for
CT2S sensors
0..380 C
Terminals
Screw terminal on
the mains voltage
side 2,5mm
2
Screw terminals on
the control side
1,5mm
2
Display
Color dispaly
480x272 with touch
panel
External dimensions
Control panel:
164x90x40 mm
Executive module:
140x90x65 mm
Total weight
1,0 kg
Norms
PN-EN 60730-2-9
PN-EN 60730-1
Software class
A
Protection class
To be built into
class I devices
3
This is the current consumed by the regulator (after
connecting 2 executive modules and panel). Total
electricity consumption depends on devices connected to
the regulator.
4
IP20 – from the front side of the executive module,
IP00 – from the side of terminals of the executive
module.
12 Conditions of storage and
transport
The regulator cannot be exposed to direct
effects of weather, i.e. rain and sunlight.
Storage and transport temperature cannot
exceed the range of -15…65 °C.
During transport, the device cannot be
exposed to vibrations greater than those
typical of normal road transport.
13 MOUNTING REQUIREMENTS
Basic version of the equipment is composed
of three modules: control panel and two
working modules. All components are
electrically interconnected.
13.1 Environmental conditions
Due to the risk of fire is prohibited to use the
controller in explosive gas and dust
enviroment (eg coal). Regulator should be
separated using appropriate enclosure.
In addition, controller cannot be used in the
presence of water vapor condensation and be
exposed to water.
13.2 Installation requirements
The regulator should be installed by a
qualified and authorised fitter, in accordance
with the applicable norms and regulations.
The manufacturer bears no responsibility for
damages caused by failure to observe this
manual.
The regulator is to be built-in. The regulator
cannot be used as a stand-alone device.
The temperature of the ambient and the
fitting surface cannot exceed the range of 0 -
50˚C. In the basic version, the device
consists of three modules, including control
panel and two executive modules. All parts
are electrically interconnected.
13.3 Assembly of control panel
Control panel is designed to be attached to a
mounting plate. Provide appropriate heat
insulation between hot boiler walls and
control panel and cable harness. Space
required to assemble control panel of the
regulator is shown in Fig. 24. When installing
follow the instructions given below.
