9 Technical details about the “plusoptiX S16”
Measurement values
Metered value
Measurement range and tolerance
Sphere
-7 to +5 dpt in 0.25 dpt steps ± 0.25 dpt
Cylinder
-7 to +5 dpt in 0.25 dpt steps ± 0.25 dpt
Axis
1 to 180° in 1° steps ± 15°
Spherical equivalent
-7 to +5 dpt in 0,25 dpt increments ± 0,25 dpt
Pupil diameter
3 to 8 mm in 0.1 mm steps ± 5%
Gaze asymmetry
0 to 25° in 0.1° steps ± 5%
Interpupillary distance
25 to 85 mm in 0.1 mm steps ± 5%
Interfaces and standards
Interfaces
USB, DVI, IR
WLAN, LAN (RJ-45)
“plusoptiX S16” screen
Diagonal 4.3‘‘, aspect ratio 5:3 (800 x 480 pixels)
Resistive contact sensor
Standards
IEC 60601-1
IR
Plusoptix devices use infrared light with a wavelength of
870nm and a maximum intensity of 135mW/sr.
WLAN interface standards:
Physical layer
Supports 802.11 b and g standards
Network architecture types
Communication with cabled networks via access points
Security
WPA and WPA2
Transmit power
802.11b/g: 50 mW (+17 dBm) typically
Frequency range
2,400 - 2,4897 GHz
Operating channels
1-11 for North America and other,
1-13 for Europe and other
Channels
Supports all channels of 802.11d-APs.
RX sensitivity
-86 dBm typically @ 11 Mbps,
-82 dBm @ 6 Mbps,
-69 dBm @ 54 Mbps
Data rates
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
Power supply
Only use the GSM36P12-P1J power supply provided.
Medical power adapter
(GSM36P12-P1J power supply)
Input
100 - 240 VAC, 50/60 Hz, 0,9 - 0,45 A
Output
12 VDC, 3A, 36 W max.
