3.2 Integrated interfaces
The cradle has 4 connections:
- LAN connection (RJ45) for incorporation into the practice network
- 12V connection for the medical power supply
- 4 x USB interfaces
- DVI connection for optional connection of a monitor
The four USB interfaces can be used as follows:
- To save the screening reports and import an infographic
- To import patient data
- To export data
- Optional connection of a USB keyboard and USB mouse
3.3 Connecting an external monitor (optional)
The “plusoptiX S16” has a DVI interface to connect an external monitor. This enlarges the
display of the results pages. This allows the results pages to be discussed easily with the
patient.
Connect your monitor with the DVI interface in the cradle of the “plusoptiX S16”. When the
device is mounted on the cradle, the image is shown on the external monitor and the screen
of the “plusoptiX S16” is turned off.
Remove the device from the cradle before the measurement. The screen of the
“plusoptiX S16” is now active and the external monitor is switched off. This avoids the child
being distracted by the picture on the external monitor during the measurement.
After the measurement, replace the device on the cradle. The screen of the “plusoptiX S16”
is now turned off again and the screen of the monitor shows an enlarged view of the results
pages.
3.4 Connecting the USB keyboard and mouse (optional)
To enter data on the “plusoptiX S16”, it is necessary to connect a conventional USB
keyboard. Connect your input device with the USB interface of the “plusoptiX S16”. You can
also connect wireless input devices instead of cabled ones.
A USB keyboard is necessary for:
- inputting and selection of patient data
- entering the password in the WLAN settings
- configuring network settings to connect to the practice network
If a connected mouse or keyboard is not working, please check whether the USB keyboard
or mouse is switched on, connected with the “plusoptiX S16” and whether the batteries are
inserted. If your input device still doesn’t work, this means it is not supported by the drivers
installed in the “plusoptiX S16”. Use input devices from another manufacturer instead in this
case.
Note:
Non-functioning external input devices do not constitute a service or warranty
case!
