To install the external temperature sensor:
1. Insert the connector end of the tether
into the jack marked “TEMP,” located on
the back of the compass.
2. Adhere the sensor end of the tether
outside of the passenger compartment.
Make sure the mounting surface is free of
oil and dirt.
3. (Optional, but suggested) Use the
included retainer clips to secure the
temperature tether to the windshield or
dashboard.
If the temperature sensor is not plugged
in and is toggled to “outside
temperature” display, the message
“PLUG IN TEMP CABLE” will scroll in
the upper right corner three times, then
will display “_ _ _ °F.”
Do not leave the PNI V6000 in a parked
vehicle that is likely to be exposed to
extremely hot or cold temperatures.
A 30-foot temperature sensor is
available at additional cost. See
INSTALLATION
