Rel. 03
41
extra-stroke position
Resetting cycle in progress Wait for the completion of the machine resetting before starting
the working cycle
Unadjusted axes Carry out the axes resetting cycle
Heating operation Check the spindles engines working
Open doors safety Close the lateral door
Machine working manually Signalling of the machine status, that is to say the selector is in
manual position (right position). In order to be able to work,
rotate the selector in the “Automatic” position (selector in
central position)
Drive ok X axis lacking
Drive ok X axis lacking
Drive ok Y axis lacking
Contact our assistance service
Board release waiting The working cycle has been completed, the board can be
released. Press the pedal to release pressers
Standby lock panel
Machine ready for work. Press the pedal to lock the panel.
Override value lower than 20% The override value is too low (lower than 20%), the drilling
cycle is blocked. Increase the override value in the
“Semiautomatic” section.
Missing from the spindle at rest
Remove the panel indicate spindles at rest see Chapter 7.4
Error size panel outside tolerance
limits
The length of the panel work is not within the tolerance.
BLU LINE FAILURES
Number Description Solution
E.1 Wrong working The tip or spindle are not authorized to carry out that specific
working cycle
E.2 Unknow tool
category
Change the tool category in the “Tool” table, “Machine Data
Editor” section
E.3 Wrong diameter Change hole diameter in the picture
Or change tip of the software equipping
E.4 Wrong tool type Change the tool type in the “Tool” table “Machine Data Editor”
section
E.6 Wrong tip thickness Change tip thickness in the “Tool” table “Machine Data Editor”
section
E.7 Wrong AZ angle Change drawing. Head with angle other than the one required
E.8 Wrong AR angle Change drawing. Head with angle other than the one required
E.11 Under Y-min limit
E.12 Over Y-max limit
During working cycle, Y axis overcomes safety limits.
Due to:
• Hole position (in Y axis of the machine) out of the limits
allowed
E.13 Under Z-min limit
E.14 Over Z-max limit
During working cycle, Z axis overcomes safety limits.
Due to:
• Drilling depth higher than the one allowed for the length
of mounted tip
• Hole position (in Z axis of the machine) higher than the
one allowed
E.15 Wrong working
speed
Working speed specified in the drawing is not consistent with
the tool working speed listed in the “Tool” table, “Machine Data
Editor” section
E15 No programme
selected
List failure set up. Follow the instructions
E.19 No tool mounted Enter one tool in the “Conf1” section of selected spindle
