CelloTrack LTE Plus Overview
CelloTrack XT LTE Overview.docx Page 35 of 40
Copyright © 2020 by Pointer Telocation, Ltd.
7 CelloTrack LTE Plus Specifications
Battery charging temperature range -20°C to 60°C
LTE Cat 1 NA with 3G Fallback
LTE NA: Bands 2, 4, 5, 12 (700, 850, 1700/2100
(AWS), 1900 MHz), data rates: 10.2[DL] /
5.2[UL] Mbps
3G NA: UMTS Bands 5, 4, 2 (850, 1700/2100 (AWS),
1900); HSPA 5.76[UL]/7.2[DL] Mbps
Packet Data: TCP/IP, UDP/IP
SMS: PDU mode
Internal, Micro Sim, replaceable, 1.8/3V
Optional SIM on chip
Remote PIN code management
Internal, multi band antenna
Internal module, CSR SiRFstarV™ based
GPS and GLONSS supported.
Cold <27 Sec, Warm<10 Sec, Hot<1 Sec
Internal, on board patch antenna
Two configurable ports supporting true GPIO (General
Purpose Input Output). Each I/O port supports:
Discrete Dry Input
Discrete Wet Input
Analog 0-2.5V Input
Analog 0-30V Input
Frequency Counter Input
Output
Discrete Dry – Ground sensing. Configurable ground
threshold.
Discrete wet – Logic 1 and 0 Configurable
thresholds.
Analog inputs with variable resolution -
8bit - 0-2.5V: 20mV resolution, accuracy ±30mV;
8bit - 0-30V: 100mV resolution, accuracy ±100mV
