CelloTrack LTE Plus Overview
CelloTrack XT LTE Overview.docx Page 38 of 40
Copyright © 2020 by Pointer Telocation, Ltd.
8 CelloTrack Release Package
The release package of the CelloTrack LTE includes, in addition to the components
mentioned in the CelloTrack 10y Hardware Components section, a number of software
tools and documents, as described in the following sections.
8.1 Evaluation Suite
The Evaluation Suite is the application which contains all the software components
necessary for the evaluation of any Cellocator unit. The software components required
for evaluating the CelloTrack LTE are described below.
8.1.1 Communication Center
The Communication Center also supports the KML generator. The Keyhole Markup
Language (KML) is an XML notation for expressing geographic annotations and
visualizations within Internet-based, two-dimensional maps and three-dimensional
Earth browsers, such as Google Earth, Google Maps, and Google Maps for Mobile.
For more details about the new Communication Center capabilities and usage during
the integration process, refer to the Cellocator Evaluation Suite Manual.
8.1.2 Cellocator Programmer
The concept of operation and parameters flow between the four entities of HW,
Programmer screen, storage and CelloTrack LTE Editor is shown below:
Figure 1: Operation Flow
The Cellocator Programmer supports the CelloTrack LTE Editor which can read, edit
and write PL parameters for CelloTrack LTE and MultiSense devices.
File save
File open
or
Open 10y Editor or Read from PL
Write to PL
Upload parameters
Download parameters
Dashboard
direct link
Dashboard / Sensors status tabs
Sensors configuration tab
2
1
5
3
4
6
