Instruction manual RT 2014
POL-EKO-APARATURA sp.j. • ul. Kokoszycka 172 C • 44-300 Wodzisław Śl. • tel./fax +48/ 32 453 91 70 • e-mail info@pol-eko.com.pl
18
11 ACCESSORIES
11.1 Measurement sensors
Parameters of RT2014 sensor:
Name
Appearance
Description
Measurement range
Cable
length
[m]
PT100 H
Sensor for high tem-
peratures (recom-
mended for CL, SL)
temp.:0…+400°C
2,5
PT100 S
Standard temperature
sensor
(recommended for KK,
ST, IL, CHL)
temp.:-40…+180°C
2,5
PT100 L
Sensor for low tem-
peratures (recom-
mended for ZL)
temp.:-110…+120°C
2,5
RH_STD
Humidity and tempera-
ture sensor (recom-
mended for ST, IL)
RH: 0…80%
temp.:-0…+60°C
2,5
RH_PREM
Humidity and tempera-
ture sensor (recom-
mended for KK)
RH: 0…100%
temp.:-50…+60°C
2,5
HP
-
Internal pressure
sensor
-
-
11.2 Fitting
Fitting enables to install the data logger RT2014 to any flat surface.
Parts supplied in the set:
1) Fitting – ‘wall’ part (1pc.),
2) Fitting – installation part (1pc.),
3) Screws M3x6mm (3pcs.),
4) Dowels (2pcs.),
5) Screws (2pcs.)
ATTENTION: using longer screws than 6mm (different than supplied) will cause
permanent damage of the device!
4
1
3
2
5
