Polaris 700 Fusion 2006 User Manual

1.13
SPECIFICATIONS
Table 1-69: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l 4.5/4.3
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-70: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .82/2.1
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.5/1-1.3
Table 1-71: Front Suspension
Suspension type Edge
IFS shocks Nitrex/7041932
IFS spring rate
lbs-in/kg-mm
100/1.79
Spring installed length in/cm 9.81/24.9
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-72: Rear Suspension
Suspension type Edge
Front track shock (FTS) Arvin/7041939
FTS spring rate
lbs-in/kg-mm
200/3.58
FTS spring installed length Fixed
Rear track shock Fox/7042129*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-73: Torsion spring
Torsion spring PNs
(LH/RH)
7041942/7041943
Torsion spring diameter in/mm .375/9.5
Torsion spring tail angle 77_
Table 1-74: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 469/212.9
Table 1-75: Electrical
Ignition timing 26_@3000
Spark plug gap in/mm .028/.71
Spark plug Champion RN3C
Voltage regulator/output 200watt
Magneto pulse 2
CDI marking IU2212
