REAR SUSPENSION
SHOCK INFORMATION
*=Rebuildable shock
b=IFP depth measured form the bottom of the shock body
t=IFP depth measured form the top of the shock body.
rr=top of remote reservoir
Table 11-5: Front Track Shocks
SHOCK PN BRAND
Extended
Length (in)
Collapsed
Length (in)
Stroke
(in)
Shock
Rod (in)
IFP Depth
(in)
Shaft PN PSI
7041939 Arvin 12.16 8.58 3.59 .50 N/A N/A N/A
7043096* Walker 12.10 8.60 3.50 .625 2.25 rr 1800227 200
7042085 Arvin 12.49 8.92 3.58 .43 N/A N/A N/A
7041486 Arvin 18.04 13.03 5.99 .49 N/A N/A N/A
7041975* Arvin 12.10 8.60 3.5 .49 4.61 t 1700026 200
7043178* Arvin 12.10 8.60 3.5 .49 4.68 t 1700026 200
7042224* Fox 12.52 5.78 3.34 .49 1.150 b 1500247 300
7043123*
Fox/M-10
128/136
12.53 5.78 3.34 .49 1.250 b 1500736 300
7042335* Arvin 12.51 8.92 3.59 .49 4.77 t 1700182 200
7043048 Arvin 12.49 8.92 3.58 .43 N/A N/A N/A
7043142* Fox 12.51 8.92 3.59 .49 .840 b 1500713 200
Table 11-6: Rear Track Shocks
SHOCK PN BRAND
Extended
Length (in)
Collapsed
Length (in)
Stroke
(in)
Shock
Rod (in)
IFP Depth
(in)
Shaft PN PSI
7041920 Arvin 16.71 10.96 5.75 .49 N/A N/A N/A
7042129* Fox 16.65 11.05 5.60 .49 1.10 b 1500487 200
7042138 Arvin 16.71 10.96 5.75 .49 N/A N/A N/A
7042058 Arvin 16.71 10.96 5.75 .49 N/A N/A N/A
7042141* Arvin 13.47 8.82 4.64 .49 N/A 1700215 300
7043097* Walker 15.60 10.56 5.04 .625 2.25 rr 1800228 200
7043177* Fox 15.60 10.56 5.04 .49 1.22 b 1500599 200
7042216* Fox 14.12 9.40 4.66 .62 2.25-2.40 rr 1500447 300
7043190* Fox 14.12 N/A N/A .498 2.40 rr 1500562 300
7043047 Arvin 16.71 10.96 5.75 .49 N/A N/A N/A
7043046* Arvin 16.61 10.97 5.64 .49 1.80 1700220 200
7043143* Fox 16.60 N/A 5.69 .498 1.75 rr 1500715 200
