7.24
CLUTCHING
DRIVEN SPRINGS
Table 7-12: TEAM Driven Spring Data
PART NUMBER COLOR WIRE DIAMETER LOAD @ 2.2″(lbs) LOAD @ 1.1″(lbs) Rate (Lbs. per inch)
7042181 Black/Yellow .200 145 208 56
7043058 Red/Black .218 140 240 90
7043059 Red/Green .218 120 220 90
7042066 Green/Black .200 135 198 56
7043061 Red/Silver .207 125 175 45
7043062 Red/Yellow .207 100 150 45
7043057 Red/Blue .218 140 200 54
7043063 Black/Red .218 155 222 65
7043064 Blue/Black .218 123 203 73
7043060 Red/White .218 100 200 91
7043069 Red/Pink .235 140 260 110
Table 7-13: Polaris Driven Spring Data
PART NUMBER COLOR WIRE DIAMETER LOAD @ 2.5″(lbs) LOAD @ 1.375″(lbs)
7041198 Red .170 21 45
7041296 Blue .192 29 64
7041499 Silver .188 25 55
7041646 Silver/Blue .183 42 75
7041782 Black .177 24 49
7041501 Gold .188 24 49
7042022 Blue/Orange .192 56 90
