Polaris 700 Fusion 2006 User Manual

1.17
SPECIFICATIONS
Table 1-96: Fluids and capacities
Fuel gal/l 12.25/46.4
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT 4
Table 1-97: Track
Width in/cm 15/38
Length in/cm 136/345
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
3/8” - 1/2” (.95-1.27cm)
Table 1-98: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041932
IFS spring rate
lbs-in/kg-mm
100/1.79
Spring installed length in/cm 9.81/24.9
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-99: Rear Suspension
Suspension type Edge
Front track shock (FTS) Arvin/7041939
FTS spring rate
lbs-in/kg-mm
200 Var/3.6
FTS spring installed length
in/cm
7.5/19.1
Rear track shock Arvin/7042138
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-100: Torsion spring
Torsion spring PNs
(LH/RH)
7041940/7041941
Torsion spring diameter in/mm
.405/10.3
Torsion spring tail angle
77_
Table 1-101: Dimensions
Width in/cm 48/121.9
Length in/cm 128/325.1
Height in/cm 49.5/125.7
Est dry weight lb/kg 517/234.7
Table 1-102: Electrical
Ignition timing 26.5_@3000RPM
Spark plug gap in/mm .028/.70
Spark plug NGK BR8ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7245
