Polaris 700 Fusion 2006 User Manual

1.19
SPECIFICATIONS
Table 1-109: Fluids and capacities
Fuel gal/l 12.25/46.4
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-110: Track
Width in/cm 15/38
Length in/cm 136/345
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.75-1.0/1.9-2.5
Table 1-111: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041918
IFS spring rate
lbs-in/kg-mm
90-180/1.6-3.2
IFS Spring installed length
in/cm
9.5/24.1
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-112: Rear Suspension
Suspension type Edge Touring
Front track shock (FTS) Arvin/7041486
FTS spring rate 90-150/1.6-2.7
FTS spring installed length 10.375/26.4
Rear track shock (RTS) Arvin/7042141*
RTS spring rate lbs-in/kg-
mm
180-900/3.2-16.1
RTS spring installed length
in/cm
10/25.4
Rear travel in/cm 15.2/38.6
* notes that shock is rebuildable
Table 1-113: Torsion spring
Torsion spring PNs
(LH/RH)
7042240/7042241
Torsion spring diameter in/mm .405/10.3
Torsion spring tail angle 77_
Table 1-114: Dimensions
Width in/cm 48/122
Length in/cm 128/325
Height in/cm 49.5/126
Est dry weight lb/kg 570/258.8
Table 1-115: Electrical
Ignition timing
27_@3000
14_@6500
Spark plug gap in/mm .028/.70
Spark plug NGK BR9ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7242
