Polaris 700 Fusion 2006 User Manual

1.23
SPECIFICATIONS
Table 1-136: IQ Track
Width in/cm 15/38
Length in/cm 136/345
Lug height in/cm 1/2.5
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.875-1.13/2.2-2.9
Table 1-137: Front Suspension
Suspension type IQ 42.5
IFS shocks Arvin/7043054
IFS spring rate lbs-in/kg-mm 120/2.2
Spring installed length in/cm 9.95/25.3
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/cm 2.25±.31/5.7±.79
Toe in/mm 0-.12/0-3.0
Table 1-138: M-10 Rear Suspension
Suspension type M-10 136
Front track shock Fox/7043123*
Front track shock spring rate
lbs-in/kg-mm
220/3.9
Spring installed length in/cm 8.5/21.6
Rear track shock Fox/7043190*
Upper Spring
lbs-in/kg-mm
273/4.9
Lower outer spring
lbs-in/kg-mm
715/12.8
Lower inner spring
lbs-in/kg-mm
425/7.6
Rear travel in/cm 14/35.6
* notes that shock is rebuildable
Table 1-139: Dimensions
Width in/cm 48/121.9
Length in/cm 129/327.7
Height in/cm 53/134.6
Est dry weight lb/kg 598/271.5
Table 1-140: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
