SPECIFICATIONS
Table 1-147: Fluids and capacities
Fuel gal/l 11/41.6
Oil qts/l 2/1.9
Coolant qts/l 3.4/3.2
Gearcase oz/ml 20/591.5
Brake fluid type DOT4
Table 1-148: Track
Width in/cm 20/51
Length in/cm 156/396
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.75-1.0/1.9-2.5
Table 1-149: Front Suspension
Suspension type 38”
IFS shocks Arvin/7041535
IFS spring rate
lbs-in/kg-mm
105/1.9
Spring installed length in/cm 9.25/23.5
Front vertical travel in/cm 7.25/18.4
Ski center distance in/cm 38/96.5
Camber in/mm .82±.72/20.8±18.3
Toe in/mm 0-.12/0-3
Table 1-150: Rear Suspension
Suspension type Slide Rail Coupled
Front track shock (FTS) Arvin 7041742
FTS spring rate
lbs-in/kg-mm
181/3.2
FTS spring installed length
in/cm
Fixed
Rear track shock Arvin/7042309
Rear travel in/cm 9/22.9
* notes that shock is rebuildable
Table 1-151: Torsion spring
Torsion spring PNs
(LH/RH)
7041239/7041240
Torsion spring diameter in/mm .468/11.9
Torsion spring tail angle N/A
Table 1-152: Dimensions
Width in/cm 43.5/110
Length in/cm 128/325
Height in/cm 51/130
Est dry weight lb/kg 643/291.9
Table 1-153: Electrical
Ignition timing 28_@3000
Spark plug gap in/mm .028/.71
Spark plug Champion RN3C
Voltage regulator/output 200watt
Magneto pulse 2
CDI marking IU2212
