Polaris 700 Fusion 2006 User Manual

1.27
SPECIFICATIONS
Table 1-160: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l 5.6/5.3
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-161: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .91/2.3
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.5/1-1.3
Table 1-162: Front Suspension
Suspension type Edge
IFS shocks Arvin/7042211
IFS spring rate
lbs-in/kg-mm
68-160/1.22-2.9
IFS Spring installed length
in/cm
10.5/26.7
Front vertical travel in/cm 10.3/26.2
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-163: Rear Suspension
Front track shock Arvin/7041975
FTS Spring rate
lbs-in/kg-mm
160 Var/2.86 Var
FTS Spring installed length 7.46/18.9
Rear track shock Fox/7042129*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-164: Torsion spring
Torsion spring PNs
(LH/RH)
7041935/7041936
Torsion spring diameter in/mm .375/9.5
Torsion spring tail angle 77
Table 1-165: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 46/117
Est dry weight lb/kg 481/218.4
Table 1-166: Electrical
Ignition timing 25_@2500RPM
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
Voltage regulator/output 280watt
Magneto pulse 6
CDI marking 4010829
