1.35
SPECIFICATIONS
Table 1-217: IQ Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1.25/3.175
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
Table 1-218: M-10 Track
Width in/cm 15/38
Length in/cm 128/325
Lug height in/cm 1.25/3.175
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
7/8” - 1 1/8” (2.2 - 2.9cm)
Table 1-219: Front Suspension
Suspension type IQ 42.5
IFS shocks Arvin/7042258*
IFS spring rate lbs-in/kg-mm 120/2.2
Spring installed length in/cm 11.17/28.4
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/cm 2.25±.31/5.7±.79
Toe in/mm 0-.12/0-3.0
Table 1-220: IQ Rear Suspension
Suspension type IQ 121
Front track shock Arvin/7043178*
Front track shock spring rate
lbs-in/kg-mm
130-270/2.3-4.8
Spring installed length in/cm 7.97/20.2
Rear track shock Fox/7043177*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-221: M-10 Rear Suspension
Suspension type M-10 128
Front track shock Fox/7043123*
Front track shock spring rate
lbs-in/kg-mm
160/2.9
Spring installed length in/cm 8/20.3
Rear track shock Fox/7043190*
Lower outer spring lbs-in/
kg-mm
715/12.8
Lower inner spring lbs-in/
kg-mm
425/7.6
Upper spring lbs-in/kg-mm 273/4.9
Rear vertical travel in/cm 10/25.4
Rear idler wheel travel in/cm 13.06/33.2
* notes that shock is rebuildable
Table 1-222: Torsion spring
Torsion spring PNs
(LH/RH)
7043070/7043071
Torsion spring diameter in/mm .347/8.8
Torsion spring tail angle 80_
Table 1-223: Dimensions
Width in/cm 46.5/118
Length in/cm 128/325
Height in/cm 46.5/118
Est dry weight lb/kg 489/222
Table 1-224: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug
Champion RN57YCC
