Polaris 700 Fusion 2006 User Manual

1.43
SPECIFICATIONS
Table 1-269: Chaincase
Center distance in/cm 8.373/21.27
Reverse type PERC
Table 1-270: Fluids and capacities
Fuel gal/l 10.8/40.9
Oil qts/l 3/2.8
Coolant qts/l 5/4.7
Chaincase oz/ml 11/325.3
Brake fluid type DOT 4
Table 1-271: Track
Width in/cm 15/38
Length in/cm 144/366
Lug height in/cm 2/5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.50/1-1.3
Table 1-272: Front Suspension
Suspension type IQ Mountain
IFS shocks Arvin/7043049
IFS shocks option Arvin/7043090*
IFS spring rate
lbs-in/kg-mm
100/1.79
IFS spring installed length
in/cm
10.35/26.3
Front vertical travel in/cm 9/22.9
Ski center distance in/cm 41/104
Camber in/cm 2.17±.31/5.5±.79
Toe in/mm 0-.12/0-3.0
Table 1-273: Rear Suspension
Suspension type IQ RMK 144
Front track shock (FTS) Arvin/7043048
FTS spring rate
lbs-in/kg-mm
170/3.0
FTS spring installed length
in/cm
7.4/18.8
Front track shock option Arvin/7042335*
FTS option spring rate
lbs-in/kg-mm
170/3.0
FTS option spring installed
length in/cm
7.25/18.4
Rear track shock Arvin/7043047*
Rear track shock option Arvin/7043046*
Rear travel in/cm 16.5/41.9
* notes that shock is rebuildable
Table 1-274: Torsion spring
Torsion spring PNs
(LH/RH)
7041629/7041630
Torsion spring diameter in/mm .359/9.12
Torsion spring tail angle 77_
Table 1-275: Dimensions
Width in/cm 46.5/118
Length in/cm 128/325
Height in/cm 46.5/118
Est dry weight lb/kg 489/222
Table 1-276: Electrical
Ignition timing
26_@3500 w/TPS
unplugged
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
Voltage regulator/output 400w@4000RPM
CDI marking 4011033
