Polaris 700 Fusion 2006 User Manual

1.47
SPECIFICATIONS
Table 1-297: Track
Width in/cm 15/38
Length in/cm 151/384
Length in/cm 159/404
Length in/cm 166/422
151 Lug height in/cm 2/5
159/166 Lug height in/cm
2.4/6.1
Track tension sag in/cm with 10
lbs/4.54kg placed 16 in/40.6cm
ahead of rear idler shaft
.375-.50/1-1.3
Table 1-298: Front Suspension
Suspension type
IQ Mountain
IFS shocks Arvin/7043049
IFS spring rate lbs-in/kg-mm 100/1.8
Spring installed length in/cm Fixed
Front vertical travel in/cm 9/22.9
IFS potion shocks Arvin/7043090*
IFS option spring rate
lbs-in/kg-mm
100/1.8
IFS option spring installed
length in/cm
10/25.4
Ski center distance in/cm 41/104
Camber in/cm 2.17±.31/5.5±.79
Toe in/mm 0-.12/0-3.0
Table 1-299: IQ Rear Suspension
Suspension type IQ RMK
Front track shock (FTS) 7043048
FTS spring rate lbs-in/kg-
mm
170/3.0
FTS spring installed length
in/cm
Fixed
Front track shock (FTS)
option
Arvin/7042335*
FTS option spring rate lbs-
in/kg-mm
170/3.0
FTS option spring installed
length in/cm
7.25/18.4
Rear track shock (RTS) Arvin/7043047
RTS option Arvin/7043046*
151 Rear travel in/cm 16.5/41.9
159 Rear travel in/cm 17.5/44.5
166 Rear travel in/cm 18.5/47
* notes that shock is rebuildable
Table 1-300: Torsion spring
Torsion spring PNs
(LH/RH)
7041629/7041630
Torsion spring diameter in/mm .359/9.1
Torsion spring tail angle 77_
Table 1-301: Dimensions
Width in/cm 46.33/118
151 Length in/cm 128/325
159/161 Length in/cm 134/340
Height in/cm 46.5/118
151 Est dry weight lb/kg 532/241.5
159 Est dry weight lb/kg 539/244.7
166 Est dry weight lb/kg 550/249.7
Table 1-302: Electrical
Stator output 400w@4000RPM
Ignition timing @ 9.6-12.7%
throttle
16_@3500
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
