9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
4.39
3. Remove the fasteners
e
securing the throttle pedal
assembly to the frame support.
4. Remove the pedal assembly from the vehicle.
PPS Installation
5. Place the throttle pedal assembly on the mounting
studs and loosely install the three fasteners.
6. Torque the three mounting bolts to specification and
connect the PPS harness connection.
TORQUE
Throttle Pedal Mounting fasteners:
18 ft-lb (24 Nm)
7. Manually cycle the throttle pedal to verify the throttle
pedal moves freely.
8. Connect the negative (-) battery cable and install the
seat.
FUEL SYSTEM
