11.18
9929422 R02 - 2017-2019 ACE 900 Service Manual
© Copyright Polaris Industries Inc.
INDICATOR LAMPS
q
Check Engine
This indicator appears if an EFI-related fault occurs. Do not operate the vehicle if this warning appears.
Serious engine damage could result. Your authorized POLARIS dealer can assist.
w
EPS Warning (if equipped)
This indicator illuminates when a fault has occurred in the EPS system. Your authorized POLARIS
dealer can assist. EPS operation is possible with key on/engine off for up to 5 minutes.
e
Engine Hot
This lamp illuminates to indicate an overheated engine. If the indicator flashes, a severe overheating
condition exists.
r
Neutral
This lamp illuminates when the transmission is in neutral and the ignition key is in the ON position.
t
Helmet/Seat Belt
This lamp flashes for several seconds when the key is turned to the ON position. The lamp is a
reminder to wear helmet and seat belt (if equipped) before operating.
y
High Beam
This lamp illuminates when the headlamp switch is set to high beam.
u
Chassis Fault
If applicable.
i
Performance Limited
On models equipped with a low speed limiter, indicator light will remain on when low speed limiter is
active.
ELECTRICAL
