126
SPECIFICATIONS
BRUTUS BRUTUS HD BRUTUS HDPTO
Overall Length 122.2 in. (310.4 cm) 158 in. (401.1 cm) (with bucket installed)
Overall Width (tires) 63.2 in. (160.6 cm)
Overall Height 72.9 in. (185 cm)
Wheelbase 84 in. (213.4 cm)
Cargo Box Dimensions (Inside) 43.5 x 54 x 11.5 in. (110 x 137 x 29 cm)
Ground Clearance - Below Differential 10 in. (25.4 cm)
Ground Clearance - Below PTO NA NA 7.2 in. (18.4 cm)
Min. Turning Radius (Turf Mode) 90 in. (229 cm)
Min. Turning Radius (Two Wheel Drive) 110 in. (280 cm)
Min. Turning Radius (4 Wheel Drive) 110 in. (280 cm)
Engine YANMAR 3-Cylinder Inline Diesel
Displacement
55.1 in
3
(904 cc)
Bore x Stroke 2.83 in. x 2.91 in. (72mm x 74mm)
Lubrication System Pressurized Wet Sump
High Idle 3700 +/- 100 RPM
Low Idle 1350 +/- 100 RPM
Alternator Output 12V DC 90A
Starting System Electric
Fuel System Indirect Injection
Front Suspension Dual A-arm w/6 in. (15.2 cm) of travel
Rear Suspension DeDion w/6 in. (15.2 cm) of travel
