27
FEATURES AND CONTROLS
Instrument Cluster
Your vehicle is equipped with an instrument cluster that senses
vehicle speed from the transmission. In addition to showing
vehicle speed, the speedometer needle flashes when a warning
condition exists.
NOTICE: High water pressure may damage components. Wash the
vehicle by hand or with a garden hose using mild soap.
Certain products, including insect repellents and
chemicals, will damage the instrument cluster lens and
other plastic surfaces. Do not use alcohol to clean the
instrument cluster. Do not allow insect sprays to contact
the lens. Immediately clean off any fuel that splashes on
the instrument cluster.
Rider Information Center
The rider information display is located in the instrument clus-
ter. All segments will light up for 1 second at start-up. If the
instrument cluster fails to illuminate, a battery over-voltage
may have occurred and the instrument cluster may have shut
off to protect the electronic speedometer. If this occurs, take
the vehicle to your Polaris dealer for proper diagnosis.
1. Vehicle Speed Display - Analog display of vehicle speed
in MPH or km/h.
2. Information Display Area - Odometer / Trip Meter /
Tachometer / Engine Temperature / Engine Hours /
Service Info - LCD display of the service hour interval,
total vehicle miles or km., total engine hours, a trip meter,
engine RPM and engine temperature.
1
20
10
11
12
13
14
15
16
17
18
19
2
3
3
4
5
6
7
8
9
