26
FEATURES AND CONTROLS
Instrument Cluster
Your vehicle is equipped with an instrument cluster that senses vehicle speed from the
transmission. In addition to showing vehicle speed, the speedometer needle flashes when a
warning condition exists.
NOTICE: High water pressure may damage components. Wash the vehicle by hand or with a garden
hose using mild soap.
Certain products, including insect repellents and chemicals, will damage the instrument
cluster lens and other plastic surfaces. Do not use alcohol to clean the instrument cluster.
Do not allow insect sprays to contact the lens. Immediately clean off any fuel that splashes
on the instrument cluster.
Rider Information Center
The rider information display is located in the instrument cluster. All segments will light up
for 1 second at start-up. If the instrument cluster fails to illuminate, a battery over-voltage
may have occurred and the instrument cluster may have shut off to protect the electronic
speedometer. If this occurs, take the vehicle to your POLARIS dealer for proper diagnosis.
1. Vehicle Speed (Speedometer) Display - Analog display of vehicle speed in MPH or
km/h.
2. Information Display Area - Odometer / Trip Meter / Tachometer / Engine
Temperature / Engine Hours / Service Info - LCD display of the service hour interval,
total vehicle miles or km., total engine hours, a trip meter, engine RPM and engine
temperature.
.
1
20
10
11
12
13
14
15
16
17
18
19
2
3
3
4
5
6
7
8
9
