69
PTO SYSTEM
Removing And Installing PTO Shafts (Models HDPTO)
If the utility vehicle will not be used for PTO driven attachments for extended periods of
time, it is possible to remove the PTO drive shaft assembly from the PTO clutch. This will
prevent damage to the PTO system if the utility vehicle will be used off road or if additional
ground clearance is desired.
Removing
1. Stop the engine. See page 40.
2. Make sure the PTO driveline and all rotating components have come to a complete stop
before exiting the utility vehicle.
3. Install the utility vehicle on jack stands. See page 107.
4. Remove the four bolts and remove the shield.
Bolt Installation Torque: 7-8 ft-lbs (9-10 Nm)
5. Remove the eight bolts and remove the belly pan.
Bolt Installation Torque: 7-8 ft-lbs (9-10 Nm)
To Next Page
