43
OPERATION
Hydraulic Controls (Models HD and HDPTO)
Front Auxiliary Hydraulic Operation
WARNING! Diesel fuel or hydraulic fluid under pressure can penetrate skin or eyes, causing serious
injury or death. Fluid leaks under pressure may not be visible. Use a piece of cardboard or wood to find
leaks. Do not use your bare hand. Wear safety goggles. If fluid enters skin or eyes, get immediate
medical attention from a physician familiar with this injury.
The utility vehicle engine must be running for the auxiliary hydraulic system to be activated.
1. Press the left side (1) of the auxiliary hydraulic switch to pressurize the female coupler.
2. Press the right side (2) of the auxiliary hydraulic switch to pressurize the male coupler.
3. See your attachment Owner’s Manual for detailed information.
Couplers
1
2
