ELECTRICAL 5 - 80
November 2007 GEM Service Manual
FRONT HARNESS
FRONT HARNESS CONNECTIONS
Connector Number Connects To Number of Pins in Connector
1 PSDM J1 10
2,3,4 Motor-Wiper 1
5,6 Horn 1
7 Front Harness 6
8 Switch-Brake Level Fluid 2
9,10 Switch-Brake Pressure 1
11 12 Volt Ground 1
