ELECTRICAL 5 - 84
November 2007 GEM Service Manual
CONTROLLER HARNESS
CONTROLLER HARNESS CONNECTIONS
Connector Number Connects to Number of Pins in Connector
1 Module-Motor Controller 23
2 Switch-Accelerator Pedal 10
3 Tachometer 3
4 Sensor, Motor Temperature 2
