5 - 85 ELECTRICAL
GEM Service Manual November 2007
CONTROLLER HARNESS (CONTINUED)
CONTROLLER HARNESS CONNECTIONS
Connector Number Connector to Number of Pins in Connector
5, 6 Main Contactor (Coil) 1
7 PSDM 72 Volt Ground 1
8 PSDM J5 8
