ELECTRICAL 5 - 88
November 2007 GEM Service Manual
MAIN HARNESS
PASSENGER REAR HARNESS CONNECTIONS
Connector Number Connects To Number of Pins in Connector
1 PSDM J6 8
2 72 Volt Ground 1
3 PSDM-Disconnect Switch 1
4 PSDM-BATT(-) 1
5 12 Volt Ground 1
6 Charger - Battery Temp Sensor 1
7,8 Switch-Park Brake 1
