ELECTRICAL 5 - 92
November 2007 GEM Service Manual
TAIL LIGHT HARNESS
Underneath Side of the Flat Bed
TAIL LIGHT HARNESS CONNECTIONS
Connector Number Connects To Number of Pins in Connector
1 Rear Harness 4
2,3,4 Lamp-Taillight-Left 1
5,6,7 Lamp-Taillight-Right 1
