Page 11
English
3. Plug power cord back into control unit and store
cleaner out of direct sunlight for next use.
5.2 Check for Brush Wear
The cleaner is tted with PVC brushes in front and
rear. There are raised grooves that are ''wear'' indicators
on the brushes located next to the tab connectors. As
brushes wear out, the raised groove will atten and
smoothen into the track.
Figure 13. Wear Indicators
To maintain optimal cleaner performance, replace the
brushes as soon as one of the wear indicators is smooth
or worn down (even if the blade wear is not even). It is
recommended that brushes are routinely replaced every
two (2) years.
To Replace Brushes:
1. Stand the cleaner on its end in a vertical
position.
Figure 14. Stand Cleaner Upright
2. Separate the edges of the brush, undo the tabs,
and remove the worn brush.
3. Position the new brush underneath the roller
with spikes facing downward.
Figure 15. Position the New Brush on Roller
4. Thread each tab into the slot provided and
gently feed it through until the heel comes out at
the other side of the slot.
4
Figure 16. Pull Tabs Through Each Slot
5. Use scissors to cut the tabs so they are no higher
than the spikes.
Figure 17. Cut Tabs
6. Repeat this procedure to replace the second
brush.
