102
SPECIFICATIONS
RANGER 4X4
Gross Vehic le Weight 2700 lbs. (1226 kg)
Fuel Capacity 8.5 gal. (32.2 l)
Towi ng Capa city 1500 lbs. (681 kg)
Max. Cargo Box Load 1000 lbs. (454 kg)
Overall Length 113 in. (282 cm)
Overall Width (box) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm)
Overall Height 75 in. (190.5 cm)
Wheelbase 76 in. (193 cm)
Ground Clearance 12.5 in. (31.75 cm)
Dry Weight 1185 lbs. (537 kg)(4X4)
1205 lbs. (547 kg)(NBU)
Cargo Box
(L x W x H)
58 x 42 x 10 in.
(147 x 106.7 x 25.4 cm)
Min. Turning Radius 132 in. (335.3 cm)
Engine Oil Capacity 2 qts. (2. 1 l)
Coolant Capaci ty 2.25 qts. (2. 4 l)
Engine 4 valve 4 stroke singl e cylinder
with c ounter balance
Displac ement 499 cc
Bore x Stroke 92 x 75
Pilot Jet 42.5
Main Jet 135
Needle Jet P-6 (829)
Jet Needle 4MB32-3
Air Screw 2 1/2
Alte rnator Output 250 W
Compression Ratio 10.2:1
Starting System Electric
Carbure tor 34 mm CV Mikuni
Ignition System CDI
Ignition Timing 30_ @ 5000 rpm
Spark Plug NGK BKR5E
