4.22
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
4. With the ignition turned off, disconnect the wire
harness from the ECU. Lift the connector locking
lever and rotate it up until the connector is free from
the ECU.
NOTE
Upon removing the ECU connector, you should hear a
“click” when the connector is fully open.
5. Remove the ECU from the vehicle.
6. To reinstall, reverse this procedure and tighten the
mounting screws to specification.
NOTE
Upon installing the ECU connector, you should hear a
“click” when the connector is fully closed.
TORQUE
ECU Retaining Screws:24 in-lbs (2.7 Nm)
FUEL SYSTEM - GENERAL
