9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
2.15
2. Tilt the rear cargo box and check the quick-connect
fuel line (D) at the fuel rail for signs of wear,
deterioration, damage or leakage. Replace line if
necessary.
3. Be sure fuel lines are routed and retained properly.
NOTE
Make sure lines are not kinked or pinched.
VENT LINE
1. Check the fuel tank vent line for signs of wear,
deterioration, damage or leakage. Replace every two
years.
2. Be sure vent line is routed properly and secured.
NOTE
Be sure vent line is not kinked or pinched.
Throttle Pedal Inspection
Inspect the throttle pedal (E) for free movement. Be
sure the throttle pedal returns normally when
released. Refer to Chapter 4 “Pedal Position Sensor
(PPS)” if experiencing a lack of throttle response.
ENGINE INTAKE PRE-FILTER SCREEN
SERVICE
It is recommended that the engine intake pre-filter be
inspected daily. The filter should be inspected using the
following procedure:
1. The engine intake pre-filter (A) is located just behind
the driver hip bolster on the left side of the vehicle.
2. Press in (towards the front of the unit) on intake pre-
filter tab (B) to remove it.
3. Inspect the pre-filter. If necessary, clean with soapy
water and dry with low pressure compressed air.
MAINTENANCE
