5
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5.19
REF.
PART DESCRIPTION NOTE
1
ASM., SEAT BACK
2 ASM., SEAT, BOTTOM 40,
3
ASM., SEAT, BOTTOM 40, [INCL. 4, QTY 2 OF 5,6]
4
BRACKET, SEAT HINGE, DOUBLE
5
SCREW TORQUE: 24 in-lbs. (2.7 Nm)
6
PIN, SEAT LATCH
7
KIT, SEAT BELT, 3 POINT, DRIVER
8 KIT, SEAT BELT, 3 POINT, PASSENGER
9
SCREW
10 NUT
TORQUE: 40 ft-lbs. (54 Nm)
11
WASHER, SEATBELT, RUBBER
12
GROMMET
13
BOLT
14 NUT
TORQUE: 18 ft-lbs. (24 Nm)
15
SCREW TORQUE: 24 in-lbs. (2.7 Nm)
*Crew and Bucket seat models use the same center console.
BODY / STEERING / SUSPENSION
