10.28
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
REAR DIFF SOLENOID RELAY
COLOR FUNCTION
Red / Dark Green
10-Amp fuse protected 12 Vdc
battery voltage.
Dark Green /
White
ECU input to enable relay.
Brown
Relay coil ground.
Red
Relay switched power to operate
the Rear Diff Solenoid.
Blue
Ground to energize the Rear Diff
Solenoid.
NOTE
The Rear Diff Solenoid Relay is mounted separately,
attached to the rear portion of the main frame under the
rear cargo box.
ELECTRICAL
