2.26
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
8. Remove the drain plug and allow fluid to drain
completely.
9. Clean the drain plug magnetic surface.
10. Reinstall drain plug with a new O-ring and torque to
specification.
11. Add the recommended amount of fluid through the fill
hole. Maintain the fluid level even with the bottom
threads of the fill plug hole.
FLUID CAPACITY
Recommended Front Gearcase Fluid:Polaris
Demand Drive Fluid
(PN 2877922) (Quart)
Capacity: 6.75 oz. (200 ml)
12. Reinstall fill plug with a new O-ring and torque to
specification.
TORQUE
Fill / Drain Plug:8-10 ft-lbs (11-14 Nm)
13. Check for leaks. Dispose of used fluid properly.
MAINTENANCE
