65
MAINTENANCE AND LUBRICATION
Gearcases
Transmission (Main Gearcase)
Oil Change
The drain plug (2) is located on the
bottom of the transmission. Access the
drain plug through the drain hole in the
skid plate.
1. Remove the fill plug.
2. Place a drain pan under the drain plug.
Remove the drain plug. Drain t he oil.
Dispose of used oil properly.
3. Wipe the magnetic end of the drain
plug clean to remove accumulated
metallic filings.
4. After the oil has drained completely, install a
new sealing washer.
5. Reinstall the drain plug. Torque to specification.
6. Add the recommended oil as needed. Do not overfill.
7. Reinstall the fill plug. Torque to specification.
8. Check for leaks.
2
