1.30
9926814 R08 - 2015-2016 RZR 900 2016 RZR S 1000 Service
Manual
© Copyright Polaris Industries Inc.
ITEM
TORQUE
Steering Tilt Shock
Fastener
7 ft-lb (10 Nm)
Steering Pivot Fasteners 40 ft-lb (54 Nm)
Steering Rack Mounting
Bolts
16 ft-lbs (22 Nm)
Steering Shaft to EPS Unit 15 ft-lbs (20 Nm)
Steering Shaft to Steering
Rack
48 ft-lb (65 Nm)
Steering Wheel Nut
65 ft-lbs (88 Nm)
Thermostat Cover Bolts
7 ft-lb (10 Nm)
Throttle Pedal Mounting
Fasteners
8 ft-lb (11 Nm)
Tie Rod End to Knuckle
30 ft-lbs (41 Nm) + 90°
Tie Rod Jam Nuts
14 ft-lbs (19 Nm)
Transmission Bell Crank
Nut
18 ft-lb (24 Nm)
Transmission Case Screws
20 ft-lbs (27 Nm)
Transmission Drain / Fill
Plugs
14 ft-lbs (19 Nm)
Transmission Isolator Bolt
(rear)
33 ft-lb (45 Nm)
Transmission Rear Mount
Bracket Fasteners
22 ft-lb (30 Nm)
Transmission Joint Bracket
Bolts
44 ft-lb (60 Nm)
Transmission Park Flange
Screws
10 ft-lb (14 Nm)
Transmission Sector Gear
Cover
12 ft-lb (16 Nm)
Transmission Shift Fork
Screws
10 ft-lb (14 Nm)
Transmission Snorkel Tube
Locking Screw
10 ft-lb (14 Nm)
Valve Cover Bolts
7 ft-lbs (10 Nm)
Visor Mounting Screws 8 ft-lb (11 Nm)
Voltage Regulator
Fasteners
5 ft-lb (7 Nm)
Water Pump Impeller
7 ft-lb (10 Nm) (Apply Loctite®
204™ to bolt threads)
Water Pump Cover Bolts
7 ft-lb (10 Nm) (Apply Loctite®
204™ to bolt threads)
Wheel Lug Nuts
Aluminum: 120 ft-lbs (163
Nm)
Steel: 60 ft-lb (81 Nm)
GENERAL INFORMATION
