9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
8.21
7. Align the front prop shaft paint mark with the front
gearcase input shaft mark so the holes align. Install a
new roll pin.
8. Install wheel and wheel nuts. Torque wheel nuts to
specification.
TORQUE
Wheel Lug Nuts:
Aluminum: 120 ft-lbs (163 Nm)
Steel: 60 ft-lb (81 Nm)
9. Install the center console.
REAR PROP SHAFT REMOVAL 4 1000
Rocker Panel Removal
1. Remove rear fender flare and rear fender. (Refer to
Rear Fender / Fender Flair Removal page 11.19).
2. Remove the four Torx T40 rear door mounting
fasteners
q
and remove door.
3. Remove two push rivets
w
on the b-pillar. Remove
two Torx T40 door striker fasteners
e
and remove
striker. Remove one Torx T27 fastener
r
retaining
the b-pillar cover and remove cover.
4. Remove three Torx T40 fasteners
t
from top of front
fender flare. Remove two torx T40 fasteners
y
&
u
.
Note length and location of fasteners. Remove push
rivet
i
from front of front fender flare. Remove fender
flare.
5. Remove two push rivets
o
and six Torx T40
fasteners
o
retaining the rocker panel. Remove
rocker panel from the vehicle.
Console and Lower Floor Removal
1. Remove seats and rocker panels (Refer to Rocker
Panel / Console / Floor page 11.20).
2. Remove four Torx T40 screws
q
and five push rivets
w
retaining the front console to the floor.
FINAL DRIVE
