Polaris RZR S 1000 2019

11.8
9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
HOOD / FRONT BODY
q
Front Bumper
u
Grill
w
Fright Front Fender
i
Front Bumper Cover
e
Right Front Fender Flair (50″ model has smaller flair)
o
Radiator Shroud
r
Left Front Fender
a
Screw
8 ft-lb (11 Nm)
t
Left Front Fender Flair (50″ model has smaller flair)
s
Bolt
7 ft-lb (10 Nm)
y
Hood
d
Screw
8 ft-lb (11 Nm)
BODY / FRAME
