9930588 R02 - 2017-2020 RZR 900 900/S 900/S4 1000/S 1000/S4 Service Manual
© Copyright Polaris Industries Inc.
9.5
4. Mark the location of the tie rod jam nut
w
on the tie
rod. Loosen the tie rod jam nut and unthread the tie
rod end off the tie rod.
5. Install new tie rod end and thread it back to the
original location of the other tie rod end. Tighten jam
nut to specification.
TORQUE
Tie Rod Jam Nut:
14 ft-lbs (19 Nm)
6. Install the tie rod end into the knuckle. Tighten new
fastener to specification.
TORQUE
Tie Rod End to Knuckle:
30 ft-lbs (41 Nm) + 90°
7. Install the wheel and four wheel nuts. Tighten lug nuts
to specification.
TORQUE
Wheel Lug Nuts:
Aluminum: 120 ft-lbs (163 Nm)
Steel: 60 ft-lb (81 Nm)
STEERING / SUSPENSION
