Polaroid TLAC-02255 User Manual

12
ENGLISH
13
You can enjoy picture, sound and a PC monitor by connecting a DVD player, video game system or
computer to the inputs located on the rear of the LED TV set.
• For the cable, use a commercially available audio/video cable.
• For more information about external device connections, see the operation manuals of your
external devices.
• Make sure that the corresponding cables are connected to each input. Connecting other cables
may result in a malfunction.
• VIDEO and S-VIDEO inputs: If your external device has an S-VIDEO output, S-VIDEO
connection is recommended. S-video provides a finer, more detailed picture. If inputs are
connected, S-VIDEO input takes a priority.
• Component Input (YPbPr): Picture can be displayed only when a 480i or 480p or greater signal is
received.
External Device Connections
VGA
cable
Audio
cable
HDMI
cable
Component cable
Composite
cable
Composite
cable
Camcorder
PC
DVD Player
Audio Amp
VCR
Audio
cable
Earphone
S-Video cable
or
cable TV
company
VHF/UHF
antenna
or
RF coaxial
cable
Coaxial
cable
cable receiver/satellite box
Y Pb/Cb
COMPONENT
Pr/Cr
AUDIO
S-VIDEO
VIDEO
HDMI
VGA AUDIO
AV IN
AUDIO OUT
PC
L R
AUDIOL R
COAXIAL AUDIOL R
Remote Control
1. button
2. Numeric buttons
3. Swap button
4. Menu button
5. Enter button
6. CH-List button
7. Volume +/- button
8. Zoom button
9. Sleep button
10. PP button
11. Input button
12. Mute button
13.
button
14. Guide button
15.
/ / / button
16. Favorite button
17. CH
/ button
18. Audio button
19. CCD button
20. Info button
MENU
ENTER
CH-LIST
SLEEP ZOOM
PP INFO
AUDIO CCD
FAVORITE
VOL
CH
GUIDE
SWAP
INPUT MUTE
1 2 3
4 5 6
7 8
0
9
