Poly Studio X70 System Hardware Port Descriptions
Ref. Number Port Description
1 HDMI output for the secondary monitor
2 HDMI output for the primary monitor
3 HDMI input for sharing content (for example, from a laptop)
4 USB-A ports
5 USB-C port
6 3.5 mm audio line in
7 3.5 mm audio line out
8 Expansion microphone connection
9 LAN connection for the system
10 Link-local network (LLN) connections for IP-based peripheral
devices
Note: This port is disabled and is reserved for future use.
11 Power cord port
Poly Studio X50 System Ports
The following illustration and table explain the ports on your Poly Studio X50 system.
