Table 2-17 Studio X50 and Studio X30 LED Indicators and Status (continued)
Indicator Position Status
Blinking red All Error preventing normal operation
Blinking amber Twelve alternating In a POST sequence, at least one test
results in a warning error. The system
continues to blink amber but initializes
after the sequence is complete if no
severe errors occur.
LED Status Indicators for the Studio E70 Camera
The camera provides LED indicators on the front and right side of the camera to help you understand
the camera’s behaviors when connected to a G7500, Studio X series system, or a Windows PC.
Table 2-18
Studio E70 Camera System LED Status Indicators
Color and Pattern Status
Pulsing white Boot initialization is in progress
Solid white (50% brightness) Powered on but disconnected from video system
Sleep mode
Solid white (100% brightness)
Powered on and connected to the video system
Solid green In a call or the camera is active
Pulsing amber Firmware update or factory reset in progress
Powering the System On and Off
The system powers on when you plug it in to a power source.
NOTE:
● Don’t restart or power off the system during maintenance activities (for example, while a
software update is in progress).
● If a system restart is necessary, use the system web interface, RestAPI, Telnet, or SSH. If
possible, avoid using the power cable to restart the system.
Wake the System
After a period of no activity, the system enters sleep mode (if configured by your administrator).
■
Do one of the following:
● If you’re using a touch monitor, tap the primary screen.
● If you’re using the TC8, tap the screen.
● If you’re using a Poly Trio, tap the screen.
LED Status Indicators for the Studio E70 Camera
21
