Polycom SoundPoint IP 550 Manual

AT&T Voice DNA 550 / 560
What is the Polycom SoundPoint IP 550 / 560
The Polycom SoundPoint IP 550 / 560 phones are full-featured IP
phones each with hands-free speakerphone and handset designed
for hi-fidelity wideband audio, and a built-in headset connection.
Each phone can have up to four unique phone numbers and has a
standard phone keypad, additional buttons (such as Messages,
Hold, and Redial), and four soft keys, located below the display
window, that provide additional functions based upon the status of
the phone. Both phones are equipped with a grey scale graphical
LCD display and the 560 has a dual-port gigabit Ethernet switch.
4

Polycom SoundPoint IP 550 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	48V DC
Volume control	Digital
Voice codecs	G.722
Backlight color	-
Display resolution	320 x 160 pixels
Safety	UL/C-UL; CE Mark-1; EN 60950-1; IEC 60950-1; AS/NZS 60950
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS - Anatel - GOST - C-tick - CCC
Compliance industry standards	IEEE 802.3af; IEEE 802.1p;IEEE 1329; RFC 1889

Weight and Dimensions

Weight	2045 g
