Polycom SoundPoint IP 650 Quick Reference Guide

ATAT&T Voice DNA® Quick Reference Guide
for the Polycom® SoundPoint® IP 650 and 670 Phones
Page 3
Figure Feature
1 Message light
2 Display controls
Arrows (Scroll)
Checkmark (Select)
X (Delete)
3 Feature keys
4 Mute button
5 Headset button
6 Speakerphone button
7 Microphone
8 Volume
9 Keypad
10 Hold button
© 2013 AT&T Intellectual Property. All rights reserved. AT&T, the AT&T logo and all other AT&T marks contained herein are
trademarks of AT&T Intellectual Property and/or AT&T affiliated companies. All other marks contained herein are the property
of their respective owners.

Polycom SoundPoint IP 650 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Volume control	Digital
Voice codecs	G.722
Display resolution	320 x 160 pixels
Display number of colors	Monochrome
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	24V DC / 500mA
Safety	UL 60950-1;CE Mark;CAN/CSA-C22.2 No. 60950-1-03;EN 60950-1;IEC 60950-1;AS/NZS 60950-1
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS

Weight and Dimensions

Weight	1260 g
Package weight	2045 g
